| Image sensor |
1/3” progressive scan CMOS |
| Min. illumination |
0.01lux @ F1.2, AGC on, 0 Lux with IR |
| Shutter time |
1/3s ~ 1/100,000s |
| Lens |
2.8mm @ F2.0 (4mm optional) |
| Day & night |
ICR |
| Digital noise reduction |
3D DNR |
| Wide dynamic range |
DWDR |
| Video compression |
H.264 / MJPEG / H.264+ |
| Alarm |
1/1 |
| Audio |
1/1 |
| Max. image resolution |
5MP CMOS, 2560 x 1920 |
| Frame rate |
20fps (2560×1920), 30fps (1920×1080) |
| Alarm trigger |
Motion detection, tampering alarm, intrusion detection, line crossing detection, network disconnect, IP address conflict, storage exception, storage error |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, IGMP, 802.1x, Qos, IPv6, Bonjour |
| System compatibility |
ONVIF(PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General functionalities |
Flickerless, dual stream, heartbeat, mirror, user authentication, video mask, watermark |
| Communication interface |
1 RJ45 10M / 100M ethernet port |
| On-board storage |
Built-in Micro SD/SDHC/SDXC card slot, up to 128 GB |
| Operating conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F), humidity 95% or less (non-condensing) |
| Power supply |
DC12V ± 10%, PoE (802.3af) |
| Power consumption |
Max. 5W |
| Ingress protection level |
IP67, IK8 |
| IR range |
Up to 30ft |
| Dimensions |
3.9” × 3.8” × 2.1” |
| Weight |
600g (1.32 lbs) |
