| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.006 Lux @ F1.2, 0 Lux with IR |
| Shutter Speed | 1 – 1/100,000s |
| Auto-iris | N/A |
| Day & Night | IR Cut Filter |
| Digital Noise Reduction | 3D DNR |
| WDR | 120 dB |
| 3-Axis Adjustment | Four flexible lens in one track, slide range: -180° to 180°, tilt: 0° to 135°, rotate: 0° to 355° |
| Focal Length | 2.8mm – 12mm |
| Aperture | F1.6 |
| FOV | Horizontal field of view: 30° to 96.3°Vertical field of view: 17° to 54° Diagonal field of view: 34° to 121° |
| IR Range | 30ft to 90ft |
| Wave Length | 850nm |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
| Behavior Analysis | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
| Max. Resolution | 2560 x 1920 |
| Frame Rate | 24fps @ 2560 x 1920 |
| Audio I/O | 1/1 |
| Alarm I/O | 2/2 |
| On Board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Communication Interface | 1 RJ45 10M/100M/1000M Ethernet port1 RS-485 interface (-S) |
| Material | Aluminum alloy, engineering plastics |
| Protection Level | IK10, IP67 |
| Power Supply | 12VDC, PoE |
| Power Consumption | Max. 17W |
| Working Temperature | -30°C to 60°C (-22°F to 140°F) |
| Dimensions | Ø11.42″ × 5.73″ |
| Weight | 10.3lbs |
